1-178136-3

Agastat Relays / TE Connectivity

Image may be representation. See specifications for product details.

Product Overview

Part Number:	1-178136-3
Manufacturer/Brand:	Agastat Relays / TE Connectivity
Product description	CONN HEADR 3POS STR KEY-X 30GOLD
Datasheets:	1-178136-3.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	37079 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 37079 pcs

Reference Price (In US Dollars)

1 pcs: $0.853

10 pcs: $0.774

100 pcs: $0.663

500 pcs: $0.553

1000 pcs: $0.474

5000 pcs: $0.42

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:
Qty:

Total:$0.853

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 1-178136-3

Part Number	1-178136-3	Manufacturer	Agastat Relays / TE Connectivity
Description	CONN HEADR 3POS STR KEY-X 30GOLD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	37079 pcs	Data sheet	1-178136-3.pdf
Voltage Rating	600V	Termination	Solder
Style	Board to Board or Cable	Shrouding	Shrouded - 4 Wall
Series	Dynamic D-3200	Row Spacing - Mating	-
Pitch - Mating	0.200" (5.08mm)	Packaging	Bulk
Overall Contact Length	-	Other Names	11781363 A29371
Operating Temperature	-55°C ~ 105°C	Number of Rows	1
Number of Positions Loaded	All	Number of Positions	3
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material Flammability Rating	UL94 V-0	Mated Stacking Heights	31.00mm ~ 32.50mm
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Insulation Material	Thermoplastic, Polyester, Glass Filled
Insulation Height	0.850" (21.59mm)	Insulation Color	Black
Ingress Protection	-	Features	Board Lock
Fastening Type	Detent Lock	Detailed Description	Connector Header Through Hole 3 position 0.200" (5.08mm)
Current Rating	-	Contact Type	Tab
Contact Shape	Rectangular	Contact Material	Copper Alloy
Contact Length - Post	0.150" (3.81mm)	Contact Length - Mating	-
Contact Finish Thickness - Post	-	Contact Finish Thickness - Mating	30.0µin (0.76µm)
Contact Finish - Post	Tin	Contact Finish - Mating	Gold
Connector Type	Header	Applications	General Purpose, Industrial
