281696-4

Agastat Relays / TE Connectivity

Image may be representation. See specifications for product details.

Product Overview

Part Number:	281696-4
Manufacturer/Brand:	Agastat Relays / TE Connectivity
Product description	CONN HEADER 4POS STR T/H AU
Datasheets:	281696-4.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	124205 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 124205 pcs

Reference Price (In US Dollars)

1 pcs: $0.299

10 pcs: $0.262

25 pcs: $0.246

50 pcs: $0.236

100 pcs: $0.226

250 pcs: $0.205

500 pcs: $0.185

1000 pcs: $0.164

2500 pcs: $0.149

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$0.299

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 281696-4

Part Number	281696-4	Manufacturer	Agastat Relays / TE Connectivity
Description	CONN HEADER 4POS STR T/H AU	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	124205 pcs	Data sheet	281696-4.pdf
Voltage Rating	-	Termination	Solder
Style	Board to Cable/Wire	Shrouding	Shrouded - 2 Wall
Series	HE13/HE14	Row Spacing - Mating	-
Pitch - Mating	0.100" (2.54mm)	Packaging	Bulk
Overall Contact Length	0.492" (12.50mm)	Other Names	281696-4-ND A122128
Operating Temperature	-40°C ~ 100°C	Number of Rows	1
Number of Positions Loaded	All	Number of Positions	4
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material Flammability Rating	UL94 V-0	Mated Stacking Heights	-
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Insulation Material	Thermoplastic
Insulation Height	0.449" (11.40mm)	Insulation Color	Blue
Ingress Protection	-	Features	-
Fastening Type	Friction Lock	Detailed Description	Connector Header Through Hole 4 position 0.100" (2.54mm)
Current Rating	-	Contact Type	Male Pin
Contact Shape	Square	Contact Material	Phosphor Bronze
Contact Length - Post	0.114" (2.90mm)	Contact Length - Mating	0.276" (7.00mm)
Contact Finish Thickness - Post	98.4µin (2.50µm)	Contact Finish Thickness - Mating	16.0µin (0.41µm)
Contact Finish - Post	Tin	Contact Finish - Mating	Gold
Connector Type	Header	Applications	General Purpose
