Agastat Relays / TE Connectivity
| Part Number | 6473423-2 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | SUPER SEAL 26POS CAP ASSY H AU | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5647 pcs | Data sheet | 6473423-2.pdf |
| Voltage Rating | 250V | Termination | Solder |
| Style | Board to Cable/Wire | Shrouding | Shrouded - 4 Wall |
| Series | Superseal | Row Spacing - Mating | - |
| Pitch - Mating | 0.118" (3.00mm) | Packaging | Tube |
| Overall Contact Length | - | Other Names | 6473423-2-ND A128975 |
| Operating Temperature | -40°C ~ 125°C | Number of Rows | 4 |
| Number of Positions Loaded | All | Number of Positions | 26 |
| Mounting Type | Through Hole, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | - | Mated Stacking Heights | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Polyester |
| Insulation Height | 1.079" (27.40mm) | Insulation Color | - |
| Ingress Protection | - | Features | Mounting Flange, Sealed |
| Fastening Type | Locking Ramp | Detailed Description | Connector Header Through Hole, Right Angle 26 position 0.118" (3.00mm) |
| Current Rating | Varies by Wire Gauge | Contact Type | Male Pin |
| Contact Shape | Circular | Contact Material | Brass |
| Contact Length - Post | 0.157" (4.00mm) | Contact Length - Mating | - |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | - |
| Contact Finish - Post | Tin | Contact Finish - Mating | Gold |
| Connector Type | Receptacle | Applications | Automotive |
