Allegro MicroSystems, LLC.
| Part Number | ACS714LLCTR-05B-T | Manufacturer | Allegro MicroSystems, LLC. |
|---|---|---|---|
| Description | SENSOR CURRENT HALL 5A AC/DC | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 50571 pcs | Data sheet | ACS714LLCTR-05B-T.pdf |
| Voltage - Supply | 5V | Series | - |
| Sensor Type | Hall Effect, Open Loop | Sensitivity | 185mV/A |
| Response Time | 5µs | Polarization | Bidirectional |
| Packaging | Tape & Reel (TR) | Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Output | Ratiometric, Voltage | Other Names | 620-1225-2 ACS714LLCTR05BT |
| Operating Temperature | -40°C ~ 150°C | Number of Channels | 1 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 2 (1 Year) |
| Linearity | ±1.5% | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Frequency | DC ~ 80kHz | For Measuring | AC/DC |
| Detailed Description | Current Sensor 5A 1 Channel Hall Effect, Open Loop Bidirectional 8-SOIC (0.154", 3.90mm Width) | Current - Supply (Max) | 13mA |
| Current - Sensing | 5A | Accuracy | ±1.5% |
