9159-0-00-01-00-00-03-0

Mill-Max

Image may be representation. See specifications for product details.

Product Overview

Part Number:	9159-0-00-01-00-00-03-0
Manufacturer/Brand:	Mill-Max
Product description	CONN PC PIN CIRC .018DIA TINLEAD
Datasheets:	1.9159-0-00-01-00-00-03-0.pdf 2.9159-0-00-01-00-00-03-0.pdf
RoHs Status	Contains lead / RoHS non-compliant
Stock Condition	749015 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 749015 pcs

Reference Price (In US Dollars)

1 pcs: $0.046

10 pcs: $0.041

25 pcs: $0.031

50 pcs: $0.027

100 pcs: $0.026

250 pcs: $0.022

500 pcs: $0.021

1000 pcs: $0.019

2500 pcs: $0.017

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$0.046

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 9159-0-00-01-00-00-03-0

Part Number	9159-0-00-01-00-00-03-0	Manufacturer	Mill-Max
Description	CONN PC PIN CIRC .018DIA TINLEAD	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	749015 pcs	Data sheet	1.9159-0-00-01-00-00-03-0.pdf 2.9159-0-00-01-00-00-03-0.pdf
Termination	Press-Fit, Knurled	Terminal Type	PC Pin
Terminal Style	Single End	Series	9159
Pin Size - Below Flange	0.023" (0.58mm) Dia	Pin Size - Above Flange	0.018" (0.46mm) Dia
Packaging	Bulk	Other Names	9.159E+15 9159000010000030 ED90578
Mounting Type	Through Hole	Mounting Hole Diameter	0.026" (0.66mm)
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Material - Insulation	-
Length - Overall	0.211" (5.36mm)	Length - Below Flange	0.045" (1.14mm)
Length - Above Flange	0.156" (3.96mm)	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Insulation Color	-	Insulation	Non-Insulated
Flange Diameter	0.045" (1.14mm)	Detailed Description	PC Pin Terminal Connector Through Hole Tin-Lead 0.018" (0.46mm) Dia
Contact Material	Brass Alloy	Contact Finish Thickness	200.0µin (5.08µm)
Contact Finish	Tin-Lead	Board Thickness	-
