Part Number | OD9238-24HBVXC10A | Manufacturer | Orion Fans |
---|---|---|---|
Description | FAN AXIAL 92.5X38MM 24VDC WIRE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Quantity Available | 4265 pcs | Data sheet | 1.OD9238-24HBVXC10A.pdf2.OD9238-24HBVXC10A.pdf3.OD9238-24HBVXC10A.pdf4.OD9238-24HBVXC10A.pdf5.OD9238-24HBVXC10A.pdf |
Width | 38.00mm | Weight | - |
Voltage Range | - | Voltage - Rated | 24VDC |
Termination | 4 Wire Leads | Static Pressure | 0.740 in H2O (184.3 Pa) |
Size / Dimension | Square - 92.5mm L x 92.5mm H | Series | OD9238 |
RPM | 5400 RPM | Power (Watts) | 16.00W |
Other Names | +OD9238-24HBVXC10A 1053-1288 OD9238-24HBVXC10AX OD9238-HBVX10A OD923824HBVXC10A |
Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
Noise | 58.0 dB | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced | Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
Lifetime @ Temp. | 50000 Hrs @ 40°C | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
Ingress Protection | - | Features | PWM Control, Speed Sensor (Tach) |
Fan Type | Tubeaxial | Current Rating | 0.700A |
Bearing Type | Ball | Approvals | cURus, TUV |
Air Flow | 135.0 CFM (3.78m³/min) |
