PL8205NL

Pulse Electronics CorporationPulse Electronics Corporation
PL8205NL Image
Image may be representation. See specifications for product details.

Product Overview

Part Number: PL8205NL
Manufacturer/Brand: Pulse Electronics Corporation
Product description COMMON MODE CHOKE 4.7A 2LN SMD
Datasheets: PL8205NL.pdf
RoHs Status Lead free / RoHS Compliant
Stock Condition 12459 pcs stock
Ship From Hong Kong
Shipment Way DHL/Fedex/TNT/UPS/EMS
In Stock 12459 pcs
Reference Price (In US Dollars)
1 pcs
$2.859
30 pcs
$2.339
120 pcs
$1.767
510 pcs
$1.611
1020 pcs
$1.507
Request Quote
Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]
  • Target Price:
  • Qty:
Total:$2.859

Please give us your target price if quantities greater than those displayed.

  • Part Number
  • Company Name
  • Contact Name
  • E-mail
  • Message

Specifications of PL8205NL

Part Number PL8205NL Manufacturer Pulse Electronics Corporation
Description COMMON MODE CHOKE 4.7A 2LN SMD Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 12459 pcs Data sheet PL8205NL.pdf
Voltage Rating - DC - Voltage Rating - AC -
Size / Dimension 0.770" L x 0.670" W (19.56mm x 17.02mm) Series -
Ratings - Packaging Tube
Package / Case Horizontal, 4 PC Pad Other Names 1902-1025-5
Operating Temperature -55°C ~ 130°C Number of Lines 2
Mounting Type Surface Mount Moisture Sensitivity Level (MSL) 1 (Unlimited)
Lead Free Status / RoHS Status Lead free / RoHS Compliant Height (Max) 0.390" (9.91mm)
Filter Type Power Line Features -
Detailed Description 2 Line Common Mode Choke Surface Mount 4.7A DCR 40 mOhm DC Resistance (DCR) (Max) 40 mOhm
Current Rating (Max) 4.7A Approvals -
