PC44PQ20/16Z-12-NN

TDK Corporation

Image may be representation. See specifications for product details.

Product Overview

Part Number:	PC44PQ20/16Z-12-NN
Manufacturer/Brand:	TDK Corporation
Product description	FERRITE CORE FOR SWITCHING POWER
Datasheets:	PC44PQ20/16Z-12-NN.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	144693 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 144693 pcs

Reference Price (In US Dollars)

2 pcs: $0.20

10 pcs: $0.16

50 pcs: $0.119

100 pcs: $0.106

250 pcs: $0.092

500 pcs: $0.084

1000 pcs: $0.071

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$0.20

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of PC44PQ20/16Z-12-NN

Part Number	PC44PQ20/16Z-12-NN	Manufacturer	TDK Corporation
Description	FERRITE CORE FOR SWITCHING POWER	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	144693 pcs	Data sheet	PC44PQ20/16Z-12-NN.pdf
Width	14.00mm	Tolerance	±25%
Supplier Device Package	PQ 20 x 16	Series	-
Other Names	445-175088 PC44PQ20/16Z-12	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material	PC44	Length	20.50mm
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Height	16.20mm
Gap	Ungapped	Finish	Uncoated
Effective Magnetic Volume (Ve) mm³	2310	Effective Length (le) mm	37.4
Effective Area (Ae) mm²	62	Diameter	-
Core Type	PQ	Core Factor (ΣI/A) mm1	0.605
