TLP183(GRL,E

Toshiba Semiconductor and Storage

Image may be representation. See specifications for product details.

Product Overview

Part Number:	TLP183(GRL,E
Manufacturer/Brand:	Toshiba Semiconductor and Storage
Product description	X36 PB-F TRANSISTOR OPTOCOUPLER
Datasheets:	TLP183(GRL,E.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	414765 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

Download Product Details PDF

In Stock 414765 pcs

Reference Price (In US Dollars)

125 pcs: $0.087

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:
Qty:

Total:$0.087

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of TLP183(GRL,E

Part Number	TLP183(GRL,E	Manufacturer	Toshiba Semiconductor and Storage
Description	X36 PB-F TRANSISTOR OPTOCOUPLER	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	414765 pcs	Data sheet	TLP183(GRL,E.pdf
Voltage - Output (Max)	80V	Voltage - Isolation	3750Vrms
Voltage - Forward (Vf) (Typ)	1.25V	Vce Saturation (Max)	300mV
Turn On / Turn Off Time (Typ)	3µs, 3µs	Series	-
Rise / Fall Time (Typ)	2µs, 3µs	Output Type	Transistor
Other Names	TLP183(GRLE	Operating Temperature	-55°C ~ 125°C
Number of Channels	1	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Input Type	DC	Detailed Description	Optoisolator Transistor Output 3750Vrms 1 Channel
Current Transfer Ratio (Min)	100% @ 5mA	Current Transfer Ratio (Max)	200% @ 5mA
Current - Output / Channel	50mA	Current - DC Forward (If) (Max)	50mA
