DSM7UA56101

VCC (Visual Communications Company)

Image may be representation. See specifications for product details.

Product Overview

Part Number:	DSM7UA56101
Manufacturer/Brand:	VCC (Visual Communications Company)
Product description	DISPLAY 7SEG 1 DIGIT 0.56" RED
Datasheets:	DSM7UA56101.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	16082 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 16082 pcs

Reference Price (In US Dollars)

1 pcs: $2.104

10 pcs: $1.754

25 pcs: $1.473

100 pcs: $1.262

250 pcs: $1.122

500 pcs: $1.017

1000 pcs: $0.933

2500 pcs: $0.894

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:
Qty:

Total:$2.104

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of DSM7UA56101

Part Number	DSM7UA56101	Manufacturer	VCC (Visual Communications Company)
Description	DISPLAY 7SEG 1 DIGIT 0.56" RED	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	16082 pcs	Data sheet	DSM7UA56101.pdf
Wavelength - Peak	624nm	Voltage - Forward (Vf) (Typ)	2V
Size / Dimension	0.787" H x 0.492" W x 0.083" D (20.00mm x 12.50mm x 2.10mm)	Series	DSM
Power Dissipation (Max)	70mW	Packaging	Strip
Package / Case	10-SMD, No Lead	Number of Characters	1
Moisture Sensitivity Level (MSL)	2A (4 Weeks)	Millicandela Rating	25mcd
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Display Type	7-Segment
Digit/Alpha Size	0.56" (14.22mm)	Detailed Description	Character LED Display Module Red 7-Segment 1 Character Common Anode 2V 20mA 0.787" H x 0.492" W x 0.083" D (20.00mm x 12.50mm x 2.10mm) 10-SMD, No Lead
Current - Test	20mA	Common Pin	Common Anode
Color	Red
