5-1775443-5

Agastat Relays / TE Connectivity

Image may be representation. See specifications for product details.

Product Overview

Part Number:	5-1775443-5
Manufacturer/Brand:	Agastat Relays / TE Connectivity
Product description	CONN HEADER 1.5MM 5POS VERT SMD
Datasheets:	5-1775443-5.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	244318 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 244318 pcs

Reference Price (In US Dollars)

800 pcs: $0.143

1600 pcs: $0.128

2400 pcs: $0.12

5600 pcs: $0.116

8000 pcs: $0.108

20000 pcs: $0.106

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$0.143

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 5-1775443-5

Part Number	5-1775443-5	Manufacturer	Agastat Relays / TE Connectivity
Description	CONN HEADER 1.5MM 5POS VERT SMD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	244318 pcs	Data sheet	5-1775443-5.pdf
Voltage Rating	250VAC	Termination	Solder
Style	Board to Cable/Wire	Shrouding	Shrouded - 4 Wall
Series	High Performance Interconnect (HPI)	Row Spacing - Mating	-
Pitch - Mating	0.059" (1.50mm)	Packaging	Tape & Reel (TR)
Overall Contact Length	-	Other Names	517754435 A99985TR
Operating Temperature	-55°C ~ 105°C	Number of Rows	1
Number of Positions Loaded	All	Number of Positions	5
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material Flammability Rating	UL94 V-0	Mated Stacking Heights	-
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Insulation Material	Thermoplastic
Insulation Height	0.197" (5.00mm)	Insulation Color	Natural
Ingress Protection	-	Features	Pick and Place
Fastening Type	-	Detailed Description	Connector Header Surface Mount 5 position 0.059" (1.50mm)
Current Rating	3A	Contact Type	Male Pin
Contact Shape	Square	Contact Material	Brass
Contact Length - Post	-	Contact Length - Mating	0.106" (2.70mm)
Contact Finish Thickness - Post	-	Contact Finish Thickness - Mating	100.0µin (2.54µm)
Contact Finish - Post	Tin	Contact Finish - Mating	Tin
Connector Type	Header	Applications	Automotive, General Purpose, Industrial, Medical
