PT2L7LB2

Agastat Relays / TE Connectivity

Image may be representation. See specifications for product details.

Product Overview

Part Number:	PT2L7LB2
Manufacturer/Brand:	Agastat Relays / TE Connectivity
Product description	RELAY GEN PURPOSE DPDT 12A 12V
Datasheets:	PT2L7LB2.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	3275 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

Download Product Details PDF

In Stock 3275 pcs

Reference Price (In US Dollars)

1 pcs: $11.035

10 pcs: $10.484

25 pcs: $9.932

50 pcs: $9.38

100 pcs: $8.828

250 pcs: $8.276

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$11.035

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of PT2L7LB2

Part Number	PT2L7LB2	Manufacturer	Agastat Relays / TE Connectivity
Description	RELAY GEN PURPOSE DPDT 12A 12V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	3275 pcs	Data sheet	PT2L7LB2.pdf
Turn On Voltage (Max)	9 VDC	Turn Off Voltage (Min)	1.2 VDC
Termination Style	Screw Terminal	Switching Voltage	400VAC - Max
Series	PT, SCHRACK	Release Time	18ms
Relay Type	General Purpose with Socket	Packaging	Bulk
Other Names	8-1415534-7 8-1415534-7-ND 814155347 PB1499 PT2L7LB2-ND	Operating Temperature	-40°C ~ 70°C
Operate Time	15ms	Mounting Type	DIN Rail
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Features	Diode, LED Indicator, Mechanical Indicator, Test Button	Detailed Description	General Purpose with Socket Relay DPDT (2 Form C) 12VDC Coil DIN Rail
Contact Rating (Current)	12A	Contact Material	Silver Nickel (AgNi)
Contact Form	DPDT (2 Form C)	Coil Voltage	12VDC
Coil Type	Non Latching	Coil Resistance	192 Ohms
Coil Power	750 mW	Coil Current	62.5mA
