HARTING
| Part Number | 09565515500 | Manufacturer | HARTING |
|---|---|---|---|
| Description | CONN D-SUB HD PLUG 78POS STR | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4113 pcs | Data sheet | 09565515500.pdf |
| Wire Gauge | - | Voltage Rating | - |
| Termination | Solder Cup | Shell Size, Connector Layout | 5 (DD, D) High Density |
| Shell Material, Finish | Steel, Nickel Plated | Series | - |
| Packaging | Bulk | Other Names | 09565515500-ND 1195-7096 |
| Operating Temperature | -40°C ~ 85°C | Number of Rows | 4 |
| Number of Positions | 78 | Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Housing Material | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Flange Feature | Housing/Shell (Unthreaded) |
| Features | Grounding Indents | Detailed Description | 78 Position D-Sub, High Density Plug, Male Pins Connector |
| Current Rating | 2A | Contact Type | Signal |
| Contact Material | Copper Alloy | Contact Form | Stamped |
| Contact Finish Thickness | 30.0µin (0.76µm) | Contact Finish | Gold or Gold-Palladium |
| Connector Type | Plug, Male Pins | Connector Style | D-Sub, High Density |
| Color | Black | Backset Spacing | - |
