Samtec, Inc.
| Part Number | SSM-109-S-SH-TR | Manufacturer | Samtec, Inc. |
|---|---|---|---|
| Description | CONN RCPT .100" 9POS SNGL HORZ | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 53078 pcs | Data sheet | 1.SSM-109-S-SH-TR.pdf2.SSM-109-S-SH-TR.pdf |
| Voltage Rating | 405VAC, 572VDC | Termination | Solder |
| Style | Board to Board or Cable | Series | SSM |
| Row Spacing - Mating | - | Pitch - Mating | 0.100" (2.54mm) |
| Packaging | Tape & Reel (TR) | Other Names | SAM14609TR SSM-109-S-SH-TR-ND |
| Operating Temperature | -55°C ~ 125°C | Number of Rows | 1 |
| Number of Positions Loaded | All | Number of Positions | 9 |
| Mounting Type | Surface Mount, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | - | Mated Stacking Heights | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Liquid Crystal Polymer (LCP) |
| Insulation Height | 0.125" (3.18mm) | Insulation Color | Black |
| Ingress Protection | - | Features | - |
| Fastening Type | Push-Pull | Detailed Description | 9 Position Receptacle Connector Surface Mount, Right Angle |
| Current Rating | 5.2A per Contact | Contact Type | Female Socket |
| Contact Shape | Square | Contact Material | Phosphor Bronze |
| Contact Length - Post | - | Contact Finish Thickness - Post | - |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) | Contact Finish - Post | Tin |
| Contact Finish - Mating | Gold | Connector Type | Receptacle |
| Applications | - |
